Mainconsole

IP, HD-CCTV and SD-CCTV Cameras

Capture Cards

HD SDI H.264 Hardware Compression Capture Card SCB 8000 Series

H.264 Hardware Compression Capture Card SCB 7100 Series

H.264 Hardware Compression Capture Card SCB 7000S Series

Video Resolution

NTSC : 176 x120, 352 x 240, 704 x 480, PAL : 176 x 144, 352 x 288, 704 x 576

Dimensions (W x H)

188 x 121 mm

H.264 Hardware Compression Capture Card SCB 6000S Series

Simply Plug and Play

Multi-Platform Mobile Clients

H.264,MPEG4, M-JPEG,MxPEG

Server-Client Architecture

Intelligent Search

AMWrnB

Linux-embedded

RAID 0,1,5, 5+spare,10

Support POS

Easy Installation

Web-Based Live Viewer

128CH Remote Live View

Design Highlights

Support of Point of Sale (POS)

This feature is overlaying POS data on dedicated camera channels in the liveview and playback. There is advanced search based on event log of smart detection and any text in transaction data. All transaction data is stored in SQLite format for business analysis.

Automatic Port Forwarding

No more frustration with forwarding packets through your routers firewall. Opening internet port for remote viewing and playback is now just a simple click away.*

*Auto port forwarding supports most routers with UPnP enabled.

Support of Cameras Dual Stream

This feature is for saving bandwidth. IP camera is streaming out 2 streams. First one is for recording with higher resolution, frame rate and bit rate. The second stream is for remote viewing with lower parameters.

IP camera

Recording Stream

Viewing Stream

High Resolution ( High bandwidth )

1 80 kbps

Standard Resolution ( Low bandwidth )

PTZ Control

Dual Stream

IP camera

Video Encoder

CCTV Camera

I/O Device

System Architecture NVRmini 2

Switch

C31A

Remote Live Viewer (Software)

Remote Live Viewer (Web)

iViewer (Mobile App)

C24/ C26 /C28

Feature Highlights

Remote configuration thruogh web browser

Support Stream Profile for remote live view bandwidth control (Original / 300 kbps / 100 kbps)

iPhone, iPad, Android, BlackBerry mobile clients

Support Immervision panomorph PTZ (360°)

GUI recording schedule

Digital PTZ and multi-view

E-map

Event response with email alert

Up to 128 CH remote liveview

Playback with 5 intelligent searches

POS

Digital watermark

Auto Port-forwarding

Specification

3rd Party Integration

One Platform, Total Management

CCTV / IP Camera

Remote I/O Solution

Video Analytics

License Plate Recognition (LPR)

Point of Sales (POS)

Access Control

Panomorph Lens (360°)

Mobile Applications

Metadata Applications

LPR / Access Control / POS

Integrated with flexibility

Connect up to 64 POS/LPR/Access Control

Support any direct serial-to-serial and serial-to-ethernet connections trasmitting ASCII commands.

Support direct ethernet-to-ethernet connection through SDK integration

Text Overlay, Event and Playback

Attach and detach text data from video.

Overlay text in live view and playback

User-defined event detection and alarm notifications

Event and text search with Regular Expression support

IP Camera Partners

IIACTi

CORUM

CCTV

IQInVislonS

TC S-XIIISTFIf Щ/Я t>Dallmeier 111(8111ЕНе| SEVEVEW FINE PO RENIX ф1 jj, JVC ni.v.lone OI-U-IIM ljn*

Lumenera MESSgA* /\н,о.ош 14/IOX/V PgnfS?.!!!* Hi PflLORJ? Щ^ЩШ РРфВЕ

ШШМ SASiYO seefim ШШ, sonv Ш¥i Toshiba тт И VMMsec VISION %viv®isK KcHwr ZAVIO

Solution Partners

/ISRodi laRdai

CD VI (D u.

OnVIF

falco

wjcBc* SonwMHoui SOYAL

W A Tyco International Company access comtrol system

Technology Partners >

JImmeiVision

2 Enables 360°

Accessories

Converter Box

C31A RS232 to TCP/IP Converter Metadata Solution

POS Null Modem

C31A

Mainconsole / NVRmini 2

Remote I/O Solution

Input Device

Output Device

C24 C31A C26 / C28

NVRmini 2 / Titan NVR

Output

Device

C08 RS232/422/485 to USB Converter

C26 I

Input

Device

(16 input)

Input

-►aigy(4 in / 4 out)

F Output

Mainconsole

Product Image

RS-232 Signal

RS-422 Signal

RS-485 Signal

Cable Type

Transmission Distance

Signal LED

Direct Power From USB Port

Power Consumption

Dimensions

Compliant with USB V1.0 and V2.0

5 full-duplex (TXD, RXD, CTS, RTS, GND)

4 half-duplex wires (TX+, RX+, TX-, RX- )

2 half-duplex wires (D+, D-)

USB type A to type B

RS485 Up to 4000ft (1200M)

Power on, TX, RX

Support

I/O Box

C24 16ch Digital Output Insolated RS485 Module C26 16ch Digital Input Insolated RS485 Module

C28 4ch Isolated Digital Input & 4ch Power Relay Output RS485 Module

151 x 75 x 26 mm

Product Image

Output/Input Channel

16 digital output channels

16 digital input channels with counter

4 digital input channel/4 digital output channel

Counter Channel/Frequency

N / A

16 / 100Hz

4 / 100Hz

Relay Type

N / A

N / A

2 Form A(R1,R2), 2Form C(R3, R4)

Communication Interface

RS-485 differential 2 half / duplex wires

RS-485 differential 2 half / duplex wires

RS-485

Transmission Distance

RS485 Up to 4000ft (1200M)

RS485 Up to 4000ft (1200M)

RS485 Up to 4000ft (1200M)

Power Consumption

1.5W

1.5W

2.7W

151 x 75 x 26 mm

151 x 75 x 26 mm

151 x 75 x 26 mm

I/O Card

S-IO

4ch Isolated Digital Input & 4ch Power Relay Output with RS232 to RS485 Converter

Input

Device

Mainconsole

Output

Device

S-IO

(4 in / 4 out)

Capture Card

RS232

USB Interface

Device

1.2W

Part Number

Dimensions

Case References

Over 65 Countries. 94800 Installations

We are testing a nuuo dvr card in my school district. The card so far is amazing. We have had DVRs in the district for approximately 13 years. We decided to look at bringing our district into the new generation by using NUUO.

James Slater

Technical Leader USA

NUUO brings us reliability and efficiency in IP video solutions.

De Troy Jean-Marie

Video Product Manager

France

I Gaston College

I NVR IP+

Galileo Galilei Piza International Airport

Capture Card / NVR IP+ / CMS 200 ch

Ministry of Internal Affairs NVR IP+ 445 ch

Africa

I Industrial

Transportation

Hospitality I Retail & Commercial I Education

Government

NUUO is very flexible and powerful solution and its great value is perceived by our customers.

Gustavo Rizzo

Commercial Director Brasil

Edcon

NVRmini

0 ch

NUUO provides a stable, cost effective, easy to use IP and hybrid solutions, which rivals any other product in the market.

Abie Ali

Director

South Africa

64 ch

NUUO is one of the most comprehensive and cost effective solutions in the market.

I Suwon City Surveillance Project

I NVR IP+ 172 ch

ё

I Jubail Technical Institute

I NVR IP+ 100 ch

USS Expo in Tokyo

Japan

NVRmini

1Electrical and Mechanical Services Department NVR IP+ 300 ch

Far Eastone Telecommunications Co., Ltd

NVR IP+ 128 ch

Taipei County Government

Capture Card / NVR IP+ / CMS 600 ch

Canberra Institute of Technology

NVR IP+ 100 ch

With the NUUO NVRs it is possible to convince customers with easy handling and high performance same time. The high compatibility with our cameras is also another important reason for the NUUO products. By combining SANTEC and NUUO products it is possible to build systems with very high quality.

Diestel, Lars CEO Germany

By partnering with NUUO, the decision has made us successful in offering superb video management system at a competitive price. We can foresee the great potential of Japanese market demand on a simple but powerful surveillance management software and NUUO will be a right fit for this.

Yoshifumi Harikita CEO Japan

Korea

Korea

Australia

www.nuuo.com

DISTRIBUTED BY

onuuo

NUUO Inc. (Taipei Headquarter)

C Block, 18 Sihyuan st., Jhongjheng District, Taipei, Taiwan, 10087 Tel: +886-2-2362-2260, Fax: +886-2-2362-2296 E-mail: sales@nuuo.com

NUUO USA Inc.

5874 Greenwood Road,Shreveport, LA, 71119 Tel : +1-877-241-7035 Fax : +1-318-631-3004 E-mail: sales@nuuo.com

This information reflects parts if the product range only. Technical data is subject to change. No responsibility is taken for errors in contents or printing. All mentioned brand names are registered trademarks and property of their owners.
